APS Mini Pump Station 200 Litre

Pump Station Overview:

Plug and Play APS Mini Pump Stations, ideal for small properties or house extensions, small offices/industrial units, park or holiday homes.
Easy to install and commission, we have free guides to help you install, plus a free pump station design service to enable us to give you the product most suited to your needs
We give you the most effective and efficient solution to meet your needs and budget.

Optional Extras:

High Level Alarm – c/w Battery Back-Up
£145.00 Ex Vat
110mm Diameter Inlet Pipe Seal/Hole Drill + Arbor
£98.00 Ex Vat
Macerator Pump (at an extra cost of)
£480.00 Ex Vat
Higher Head Vortex Pump (at an extra cost of)
£55.00 Ex Vat
  • 0.75kW 230V submersible pump
  • 2″ discharge with vortex impeller
  • Cast iron and stainless steel construction
  • 35mm (2″) free solids handling capacity
  • Maximum lift: 12 metres
  • Maximum flow rate: 360 litres per minute (LPM)
  • Float switch fitted as standard
  • Weight: 22.1kg

Pump

  • 0.4kW 230V submersible pump
  • 2″ discharge with vortex impeller
  • Cast iron and stainless steel construction
  • 35mm (2″) free solids handling capacity
  • Coolant-filled motor
  • Mechanical seal
  • 10 metre cable
  • Maximum lift: 7.5 metres
  • Maximum flow rate: 260 litres per minute (LPM)
  • Float switch fitted as standard
  • Weight: 18.6kg

Tank

  • Polyethylene tank.
  • Screw down lid (Pedestrian rated)
  • 2″ internal pipe work
  • 2″ non-return valve
  • 2″ quick release coupling
